Architectural Series | Series 467

Architectural Series | Series 467

Architectural Awning/Casement Window with Truth™ Hardware

Architectural Awning/Casement Window with Truth™ Hardware
Maximum Panel Height* Various
Maximum Panel Width* Various
Maximum Glass Thickness ≤ 24mm
SHGC Range 0.14 - 0.57
Uw Range 4.2 - 7
Acoustics Testing Certified AS2047 Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail techsupport@awsaustralia.com.au

Key Features / Performance Characteristics

  • This high performance awning and casement window has been designed to accept Truth™ Hardware. This allows us to offer very large casements, awnings and fixed windows fitted with scissor type winders with jamb to stile latches that secure the sashes in the closed position.
  • The extra strong sashes allow large sash windows to be fabricated for high wind load areas. Successfully tested to resist 450Pa water.
  • Fixed sidelights/lowlights and highlights can be single or double glazed.
  • The perimeter frame has been designed to make installation into brick veneer and cavity brick easier with built-in nailing fins (weather bars).
  • The Truth™ hardware can resist very high negative wind loads with the use of winders and side latches.
  • Series 467 accepts flyscreens that tuck into head and sill recess.
  • On casements it's possible to clean the external glass face when the sash is in the 90º open position.

Resources & Downloads

  • FEATURES OVERVIEW

    • Framing

      Custom sub-sill (flashing tray) standard on 467 windows.
      Framing
    • Sashes

      Custon sash designed to accept Truth™ hardware.
      Sashes
    • Jambs

      Nailing fin jamb designed to go into brick veneer construction.
      Jambs
    • Glazing

      Accepts glazing up to 25mm double glazed units.
      Glazing
    • Corners

      467 series can be coupled and adapted in various junction details.
      Corners
    • Drainage

      Concealed drainage designed to shed water more efficiently.
      Drainage
  • COMPATIBLE HARDWARE

    AWS hardware options designed for use with Series 467 Architectural Awning/Casement Window with Truth™ Hardware.

  • RELATED SYSTEMS

    AWS systems designed to share similar aesthetic and performance qualities to Series 467.

  • ALTERNATIVE SYSTEMS

    AWS systems which offer a similiar function to Series 467 but differ in aesthetics and performance.
