Architectural Series | Series 650

Architectural Series | Series 650

Architectural Hinged Door

Architectural Hinged Door
Maximum Panel Height* 3000mm
Maximum Panel Width* 1000mm
Maximum Glass Thickness ≤ 28mm
SHGC Range 0.26 - 0.6
Uw Range 4.3 - 6
Acoustics Testing Certified AS2047 Testing Certified BAL40 Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail techsupport@awsaustralia.com.au

Key Features / Performance Characteristics

  • Entry door hinged door framing system designed to accept heavy duty 50mm thick commercial swing doors.
  • 50mm wide door options including fully beaded. These heavy duty 50mm thick commercial hinged doors are ideal for oversize door panels.
  • Series 52 swing doors will accept 24mm thick insulating glass.
  • Three midrail sizes to choose from (50, 115 and 125mm deep).
  • Two door thresholds cover both internal and external swing hinged doors.
  • Sub-sills available for high performance installations.
  • Snap-fit nailing fin adapter for brick veneer and cavity brick installations.
  • The Series 650 hinged door will accept awning and casement sashes.
  • Recessed clean fixed sidelights and highlights pocket glazed similar to commercial framing.

Resources & Downloads

  • FEATURES OVERVIEW

    • Door Stop

      Unique double sided door stops allow for easy fitting of security door frame.
      Door Stop
    • Sill Type

      Externally opening door sill.

      Sill Type
    • Door Stiles

      Dedicated french door meeting stiles an option.
      Door Stiles
    • Sub-Framing

      Designed to accept sub-sill and sub-framing as required.
      Sub-Framing
    • Speciality

      Unique self-draining sills.

      Speciality
  • COMPATIBLE HARDWARE

    AWS hardware options designed for use with Series 650 Architectural Hinged Door.

  • RELATED SYSTEMS

    AWS systems designed to share similar aesthetic and performance qualities to Series 650.

  • ALTERNATIVE SYSTEMS

    AWS systems which offer a similiar function to Series 650 but differ in aesthetics and performance.
