Commercial Framing | Series 606

Commercial Framing | Series 606

Single Glazed Front Glazed 150mm Framing

Single Glazed Front Glazed 150mm Framing
Maximum Panel Height* Various
Maximum Panel Width* Various
Maximum Glass Thickness ≤ 10.38mm
SHGC Range 0.33 - 0.74
Uw Range 4.5 - 6.4
Acoustics Testing Certified AS2047 Testing Certified BAL40 Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail techsupport@awsaustralia.com.au

Key Features / Performance Characteristics

  • Series 606 FrontGLAZE™ is designed to complement Series 406 FrontGLAZE™, Series 702 and 704 SlideMASTER™ sliding doors.
  • High water resistance can be achieved, the design has been successfully tested at 600Pa water resistance.
  • Variety of transom and mullion alternatives.
  • Industry standard glazing pocket as per Series 406 FrontGLAZE™ and Series 400 CentreGLAZE™, incorporates a truly captive glazing wedge.
  • Two mullion designs allow frames to be constructed with snap together mullion and expansion mullion with central weather leg for improved waterproofing.
  • Two midrail sizes (50mm and 125mm).
  • Large variety of glazing and beading options.
  • Built-in drip groove on transoms to encourage water to leave framing face.
  • Sills and transoms are splayed at 25º to reduce the chance of dust and pollution build-up.
  • Doors can be fitted with matching 25º splayed horizontal beads.
  • Will accept awning/casement sash inlays.

Resources & Downloads

  • FEATURES OVERVIEW

    • Transoms

      Various transoms including externally glazed shown above or internally glazed.
      Transoms
    • Mullions

      Various mullion options including interlocking to allow for expansion and contraction.
      Mullions
    • Sub-Framing

      Sub-sill, head and jambs available.

      Sub-Framing
    • Thresholds

      A variety of thresholds to suit different applications.
      Thresholds
    • Pivot Doors

      Can accept concealed overhead closers and concealed floor pivots.
      Pivot Doors
    • Drainage

      Concealed drainage designed to shed water more efficiently.
      Drainage
