ViewMASTER™ Bi-Fold Door (top hung)

ViewMASTER™ Bi-Fold Door (top hung)
Maximum Panel Height* 3000mm
Maximum Panel Width* 1000mm
Maximum Glass Thickness ≤ 28mm
SHGC Range 0.14 - 0.59
Uw Range 3.3 - 6.2
Acoustics Testing Certified AS2047 Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail

Key Features / Performance Characteristics

  • Series 411 Bi-fold door (top hung) has been designed to accept the 50mm thick heavy duty Series 50 and 52 doors.
  • This bi-fold door can be manufactured with compliant panels up to 3000mm high.
  • Bi-fold doors are hung on Centor™ twin stainless steel bearing rollers running in heavy duty dual overhead tracks.
  • The standard E2 rollers on our bi-fold doors will carry door panels up to 40kg.
  • Heavy duty E3 will carry bi-fold door panels up to 80kg.
  • The Surelock™ adjustment on the pivots and carriers allow all panels to be lifted or lowered easily with a flat screwdriver. Bi-fold doors can be adjusted vertically up to 5mm plus or minus.
  • Carriers, pivots, hinges and fixings supplied in 304 SS.
  • Snap-on jamb adapter accommodates an extensive range of jambs to cover almost any situation.
  • A variety of lever and lock options are available including multi-point locking on our bi-fold doors for added security.
  • Our bi-fold doors have been successfully tested to resist 450Pa water and are suitable for air conditioned buildings when weather resisting sill is used.
  • Bi-fold doors can be configured to incorporate single or double entry doors so access can be achieved without opening the whole unit.
  • Bi-fold doors can be fitted with Centor S1E Eco Screen

Resources & Downloads


    • Top Hung

      The 411 utilises both Centor E2 and E3 running gear, the lighter E2 illustrated.
      Top Hung
    • Hardware

      A full range of hardware available including multiple 4-point locking mechanisms.
    • Adjustment

      All pivots are vertically and horizontally adjustable.
    • Compatibility

      The 411 incorporates varying profiles to be used as jambs, including corner mullion detailed.
    • Pivot

      Bottom pivot incorporates a unique adjustment system.
    • Screening

      All Elevate™ systems can incorporate Centor roll-away screens.
