Designer Series | Series 525

Designer Series | Series 525

LouvreMASTER™ Adjustable Louvre Window

LouvreMASTER™ Adjustable Louvre Window
Maximum Panel Height* 3014mm
Maximum Panel Width* 900mm
Maximum Glass Thickness ≤ 6.38mm
SHGC Range 0.32 - 0.68
Uw Range 4.6 - 6.2
AS2047 Testing Certified Safe4Kids Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail techsupport@awsaustralia.com.au

Key Features / Performance Characteristics

  • Adjustable louvre window system designed to complement the Vantage 102mm windows and doors. The jambs, head and sill will clip to all 102mm Vantage products including MAGNUM™ windows and doors.
  • 131mm overall frame is wide enough to allow the flyscreen to be fitted within the frame line, without the need for screws, rivets or unsightly turnbuckles - clean flat finish.
  • The LouvreMASTER™ louvre window system has been successfully tested to 300Pa water resistance.
  • The LouvreMASTER™ louvre window weather trims snap to head and sill and are cut between galleries - no end notching on trim or gallery channels.
  • Full height louvre window blades always give the best appearance and are the most economical.
  • The 102mm and 152mm louvre window blades can be glass, aluminium or timber.

Resources & Downloads

  • FEATURES OVERVIEW

    • Security Bar Option

      Security Bars can be installed for added security and fall prevention.
      Security Bar Option
    • Sill Options

      Various sill heights for water resistance and fixed glazing.
      Sill Options
    • Compatibility

      Can be coupled to sliding doors.
      Compatibility
    • Colour Options

      Galleries and clips can be colour matched to frame.
      Colour Options
    • Mullion Options

      Various mullion options for strength and flexibility.
      Mullion Options
