Architectural Series | Series 466

Architectural Series | Series 466

Architectural Awning / Casement Window

Architectural Awning / Casement Window
Maximum Panel Height* Various
Maximum Panel Width* Various
Maximum Glass Thickness ≤ 24mm
SHGC Range 0.14 - 0.57
Uw Range 4.2 - 7
Acoustics Testing Certified AS2047 Testing Certified BAL40 Testing Certified

* Subject to individual site conditions and wind loads. Contact AWS Technical Support for more information, e-mail

Key Features / Performance Characteristics

  • This 102mm thick commercial grade awning window has been designed with bold frame lines and thick (strong) sashes that can carry heavy glass including 24mm thick double glazing.
  • The perimeter frame has been designed to make installation into brick veneer and cavity brick easier with built-in nailing fins (weather bars).
  • The extra strong sashes allow large sash windows to be fabricated for high wind load areas.
  • Splayed or square glazing beads available.
  • Awning sashes can be fitted with cam handles, manual chain winders or concealed electric winders. The winder options suit fixed flyscreen installation.
  • Sashes are hung on heavy duty four-bar stainless steel or aluminium stays.
  • Sashes will accept a variety of glass thicknesses from 4mm single panes to 24mm insulating glass units.
  • Two non-facing (recessed) sash designs cover internal and external glazing.

Resources & Downloads


    • Operation

      466 manual chainwinder comes standard with stainless chain, body can be coloured to match.
    • Sub-Sill

      Unique self-draining sub-sill designed for reveal installation if required.
    • Sash

      466 sashes can be supplied with internal bead or external as detailed.
    • Sill

      Custom sub-sill (flashing tray) standard on 466 windows.
    • Stays

      The 466 incorporates heavy duty friction or non-friction stays.
    • Drainage

      Custom head and transom with concealed drainage designed to shed water more efficiently.
